Reliable with numerous innovative features
The Dewulf Torro is a light trailed 2-row offset bunker harvester with special attention for potato-friendliness as well as product quality. The harvester is specifically equipped with numerous innovative features for these purposes. The Torro was the first machine to use our patented Inclino Master® technology. This system ensures that the harvesting unit remains continuously parallel to the field while the harvester is kept horizontal. This technology increases profitability and avoids quality losses due to damaged potatoes during harvesting. Thanks to the Quick Change System, switching between the Torro's various harvesting kits (carrots, onions, red beet) takes just 15 minutes.
Unique curved haulm conveyor
The trailed 2-row sieving harvester with bunker has two sieving conveyors combined with a curved, ultra-potato-friendly haulm conveyor that is unique in the market. This design reduces the drop height to an absolute minimum and does a better job keeping the haulm on the haulm conveyor.
Cleaning with a minimum of power
The Torro is equipped with two flat hedgehog units. The sorting platform has room for seven people. The discharge conveyor is equipped with a waste funnel on both sides. Torro also requires little in the way of tractor power; a 100 hp tractor is adequate for harvesting. The harvester is standard equipped with a 8.6 m³ bunker with two programmable discharge speeds. If you want to significantly boost your productivity, an unloading-on-the-move bunker is also available.
- ■ = standard
- o = Optional
- - = Not applicable
Harvesting unit | |
Harvesting channel 1500 mm | ■ |
Harvesting channel 1650 mm | o |
APC (Automatic Pressure Control) | o |
DAS (Dewulf Automatic Steering) | o |
ADC (Automatic Depth Control) | o |
Inclino Master® | o |
Sieving chains | |
Length sieving conveyor 1 [mm] | 3200 |
Length sieving conveyor 2 [mm] | 2400 |
Haulm separation | |
Deviner web | ■ |
Cleaning | |
Agitator in sieving web 1 | ■ |
Flat hedgehog unit 1 with 3 deflecting rollers | ■ |
Flat hedgehog unit 2 with 2 deflecting rollers | ■ |
Flat hedgehog unit 2 with 3 rows of rubber studs | o |
Dimensions | |
Total length [mm] | 11 210 |
Total width [mm] | 3370 |
Total height [mm] | 3620 |
Weight from [kg] | 9800 |
