Product-friendly storage
The ML 70 series are store loaders with a 70 cm wide, deep troughed conveyor belt. They stand out with a high capacity of greater than 130 tonnes/h with a product-friendly belt speed. The store loaders are available in lengths of 13 or 16 metres.
Quality and reliability
Dewulf has many years of experience with the transport of potatoes. The quality of the latest generation of Miedema store loaders has been achieved in close cooperation with our end users. As a result, our store loaders provide maximum capacity, an efficient product flow and less risk of damage. At Dewulf, the strength lies in the simplicity, which makes our store loaders absolutely reliable and practically indestructible.
Extremely user-friendly
Our Miedema store loaders are equipped with various unique elements that promote the user-friendliness. Working enjoyably is often a result of specific details. The top of the store loader has a nodding section for the filling of storage buildings or lorries. Thanks to the small diameter of the returning roller, a minimum drop height is always ensured. The troughed conveyor belt guarantees a high capacity. The covered sensors for the side board detection control the reversing of the swivel direction using poles, which provides a particularly user-friendly experience. The useful remote control also contributes to this.
Working easily and safely
Dewulf has created an intelligent system called Start-Control that connects all the Miedema storage machines. This allows you to start the entire storage line with the remote control for the store loader. First the store loader/box filler starts, then the belt conveyor and finally the receiving hopper. As soon as the receiving hopper is empty, all the machines in the storage line will stop simultaneously. With the ingenious Start-Control, the optimal filling of all conveyor belts is ensured to minimise product damage and to prevent current spikes.
Three possible filling programs
The ML 70 store loaders are available with a selection of 3 possible filling programs to meet your specific needs.
Farmer
| The Farmer filling function automatically moves the store loader from side to side at a fixed speed, while the transport length and discharge height are controlled manually. |
Comfort+
| With the Comfort+ filling function, the store loader’s side-to-side movement, transport length and discharge height are all controlled automatically. If desired, the discharge height of the final terrace can be controlled automatically, allowing a hall to be filled to a consistent height. This filling function can also be used for filling Big Bags. |
Comfort
| With the Comfort filling function, the store loader’s side-to-side movement, transport length and discharge height are all controlled automatically. Starting a new terrace must be done manually. |
- ■ = standard
- o = Optional
- - = Not applicable
| ML 70 | ||
| ML 1370 | ML 1670 | |
| Minimum length [cm] | 780 | 970 |
| Maximum length [cm] | 1270 | 1576 |
| Minimum overhang [cm] | 363 | 412 |
| Maximum overhang [cm] | 915 | 1135 |
| Total width min./max. [cm] | 242/295 | |
| Minimum discharge height [cm] | 35 | |
| Start-Control | ■ | |
| Variable swivel and driving speed control | o | |
| Variable swivel and driving speed control – remote control | o | |
| Electric retraction and extension | ■ | |
| CANbus set | o | |
| Swivel limitation with poles | ■ | |
| Scraper return rollers | o | |
| Work lamp | ■ | |
| Coupler for MC / TAT | o | |
| Grain chute | o | |
| Raising kit | o | |
| Powder metering unit | o | |
| Truck filling belt | o | |
| Dwarsverplaatsingsset | o | |
